Hikmicro FH35 Falcon 35mm Thermal Imager 384x288 12mic <20mk Monocular

HIKMICRO FALCON FH35 handheld thermal monocular camera is equipped with a 384 × 288 infrared detector and a 1024 ×768 OLED display. It supports functions of observation, hotspot, and so on. The high-sensitivity built-in thermal detector provides you with clear view even in total darkness. The monocular is mainly applied to scenarios such as searching and rescuing, hiking, travel, and hunting, etc.

Key Features:

• 384 × 288 Resolution with 12μm sensor
• High sensitivity Thermal Module NETD < 20 mK (@25°C, F# = 1.0)
• Replaceable and rechargeable Li-ion battery
• Up to 7 hours continuous operation
• Leading thermal image processing technology: Image Pro
• 1024 × 768 Resolution 0.39-inch OLED display
• Specification

Thermal Module

• Image Sensor: VOx Uncooled Focal Plane Arrays
• Resolution: 384 × 288
• Frame Rate: 50 Hz
• Pixel Interval: 12 μm
• Response Waveband: 8 μm to 14 μm
• NETD: Less than 20 mK (@25°C), F# = 1.0
• Focal Length: 35 mm
• Aperture: F1.0
• Min. Focusing Distance: 3.5 m
• Digital Zoom: 1×，2×，4×，8×
• Optical Magnification: 3.03
• Field Of View (H×V), Degrees/m @100m: 7.53° × 5.65°/13.2 m × 9.9 m
• Detection Range: 1800 m

Image Display

• Monitor: 0.39 inch, OLED, 1024 × 768
• Palettes: Black Hot, White Hot, Red Hot, Fusion
• FFC (Flat Field Correction) Mode: Auto, Manual, External Correction

System

• Storage: Built-in memory module (64 GB)
• Record Video: Yes
• Capture Snapshot: Yes
• Standby Mode: Yes
• Hotspot: Yes
• Hot Track: Yes

Power Supply

• Power: 5 V, 1.5 W
• Battery Type: Replaceable and Rechargeable Li-ion Battery
• Battery Operating Time: 7 hours continuous running with CVBS and hotspot function off (@25°C)

General

• Working Temperature/Humidity: From -30°C to 55°C (-22°F to 131°F); Humidity: 90% or Less
• Protection Level: IP67
• Dimension: 190.3 mm × 58.3 mm × 65.2 mm (7.49" × 2.29" × 2.57")
• Weight: 505 g (1.11 lb)
